MEC1-108-02-F-D Real Image
Same model may have multiple batches, images only for reference.

MEC1-108-02-F-D

Part No MEC1-108-02-F-D
Manufacturer Samtec Inc.
Catalog Card Edge Connectors - Edgeboard Connectors
Description CONN EDGE DUAL FMALE 16POS 0.039 / 16 Position Female Connector Non Specified - Dual Edge Gold 0.039" (1.00mm) Black
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Card Edge Connectors>Edgeboard Connectors
Manufacturer Samtec Inc.
Packaging Tube
Card Type Non Specified - Dual Edge
Gender Female
Number of Positions 16
Card Thickness 0.062" (1.57mm)
Number of Rows 2
Pitch 0.039" (1.00mm)
Read Out Dual
Mounting Surface Mount
Termination Solder
Contact Material Beryllium Copper
Contact Finish Gold
Contact Finish Thickness 3.00µin (0.076µm)
Contact Type Loop Bellows
Color Black
Temperature Range - Operating -55°C ~ 125°C
Material - Insulation Liquid Crystal Polymer (LCP)
Base Product Number MEC1-108
RoHS Status ROHS3 Compliant
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.69.4040
Standard Package 43
Win Source Part Number 1334085-MEC1-108-02-F-D
Ultra Librarian 3D Model Ultra Librarian MEC1-108-02-F-D CAD Model

Description

The Samtec Inc. MEC1-108-02-F-D is a card edge connector in the family of connectors and interconnects.

  • Card Type: Dual Edge Non-Specified
  • Number of Positions: 16
  • Pitch: 1.00mm
  • Contact Finish: Gold
  • Contact Finish Thickness: 3.00um
  • Contact Material: Beryllium Copper
  • Insulation Material: Liquid Crystal Polymer (LCP)
  • Termination Type: Surface Mount
  • Temperature Range: -55°C to 125°C
