HTST-105-01-L-DV Real Image
Same model may have multiple batches, images only for reference.

HTST-105-01-L-DV

Part No HTST-105-01-L-DV
Manufacturer Samtec Inc.
Catalog Circular Connectors - Housings
Description CONN HEADER SMD 10POS 2.54MM / Connector Header Surface Mount 10 position 0.100" (2.54mm)
Datasheet
HTST-105-01-L-DV Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Male Pins
Mfr Samtec Inc.
Series Flex Stack, HTST
Package Tube
Connector Type Header
Contact Type Male Pin
Pitch - Mating 0.100" (2.54mm)
Number of Positions 10
Number of Rows 2
Row Spacing - Mating 0.100" (2.54mm)
Number of Positions Loaded All
Style Board to Cable/Wire
Shrouding Shrouded - 4 Wall
Mounting SMD (SMT)
Termination Solder
Fastening Type Push-Pull
Contact Length - Mating 0.250" (6.35mm)
Insulation Height 0.350" (8.89mm)
Contact Shape Square
Contact Finish - Mating Gold
Contact Finish Thickness - Mating 10.0µin (0.25µm)
Contact Finish - Post Tin
Contact Material Phosphor Bronze
Insulation Material Liquid Crystal Polymer (LCP)
Features Keying Slot
Temperature Range - Operating -55°C ~ 125°C
Material Flammability Rating UL94 V-0
Insulation Color Natural
Current Rating (Amps) 3.4A per Contact
Base Product Number HTST-105
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.69.4040
Other Names SAM8808,Q9850331,HTST-105-01-L-DV-ND
Standard Package 27
Win Source Part Number 1150904-HTST-105-01-L-DV
Ultra Librarian 3D Model Ultra Librarian HTST-105-01-L-DV CAD Model

Description

The Flex Stack HTST header connector is a connector type that features a keying slot, male pin contact type, and solder termination.

  • Connector Type: Header
  • Keying Slot: Yes
  • Contact Type: Male Pin
  • Termination: Solder
  • Style: Shrouded 4-Wall
  • Board to Cable/Wire: Yes
  • Positions Loaded: 10
  • Rows: 2
  • Contact Material: Phosphor Bronze
  • Contact Finish - Mating: Gold
  • Contact Finish - Post: Tin
  • Insulation Material: Liquid Crystal Polymer (LCP)
  • Insulation Color: Natural
  • Flammability Rating: UL94 V-0
  • Pitch: 0.100" (2.54mm)
  • Temperature Range: -55°C to 125°C
  • Current Rating: 3.4A per contact
  • Package: Tube
