The EHF-113-01-L-D-SM-LC is a rectangular connector manufactured by Samtec Inc. This connector is part of Samtec's Edge Rate® High-Speed Edge Card Socket series. These connectors are designed for high-speed and high-density applications, offering excellent signal integrity and reliable performance. The 'LC' at the end specifies a Lead Coplanarity option.

Applications

• High-speed board-to-board connections: Used for connecting PCBs in servers and networking equipment.
• Telecommunications equipment: Employed in routers, switches, and other communication devices.
• Industrial automation: Integrated into control systems and data acquisition units.
• Medical devices: Found in imaging systems and diagnostic equipment.
• Test and measurement equipment: Utilized in oscilloscopes, logic analyzers, and signal generators.

Features

• High-speed performance: Designed for data rates up to 28 Gbps.
• High-density contacts: Provides a large number of I/O connections in a small footprint.
• Edge Rate® contacts: Mates with a smooth, milled surface on the board to reduce wear and improve signal integrity.
• Surface mount termination: Facilitates automated assembly and soldering processes.
• Dual row configuration: Offers increased connection density.

Benefits

• Improved signal integrity: Edge Rate® contacts minimize impedance discontinuities and reflections.
• Increased system reliability: Robust design ensures stable and durable connections.
• Reduced manufacturing costs: Surface mount termination simplifies assembly processes.
• Enhanced system performance: High-speed capabilities enable faster data transfer rates.
• Space-saving design: High-density configuration reduces board space requirements.

Additional Details

The EHF-113-01-L-D-SM-LC connector features 26 total pins (13 per row, times 2 rows due to 'D' double row designation), and a surface mount termination style (SM). The 'L' designates the plating material, most likely gold. The connector body is typically made of high-temperature thermoplastic material, capable of withstanding reflow soldering processes. The connector is designed to mate with appropriate edge card connectors on printed circuit boards. The low lead coplanarity (LC) option helps ensure proper soldering and electrical connection across all pins. Samtec provides detailed datasheets with specifications on mating forces, durability, and environmental performance. These connectors are often used in demanding applications where high reliability and signal integrity are critical.

Electrical specifications generally include the current rating, voltage rating, and impedance. Mechanical specifications include the mating force, unmating force, and durability (number of mating cycles). Environmental specifications include the operating temperature range and humidity resistance. Careful consideration of these specifications is essential for selecting the appropriate connector for a given application.
