The Samtec Inc. CLP-105-02-F-D-P-TR is a 10-position female socket receptacle connector with a push-pull fastening mechanism.

• Pitch: 0.050" (1.27mm)
• Connection Type: Board to Board
• Insulation Material: Liquid Crystal Polymer (LCP)
• Insulation Color: Black
• Voltage Rating: 240VAC and 330VDC
• Contact Material: Phosphor Bronze
• Contact Plating (Mating): Gold
• Contact Plating (Post): Tin
• Insulation Height: 0.084" (2.14mm)
• Contact Shape: Square
• Contact Length: 0.194" (4.93mm)
• Operating Temperature: -55°C to 125°C
• Material Flammability Rating: UL94 V-0
• Packaging: Tape & Reel
• Feature: Pick and Place
