RLS4148TE-11 Rohm Semiconductor RLS4148TE-11 label picture RLS4148TE-11 label picture 2 RLS4148TE-11 real image
Same model may have multiple batches, images only for reference.
RLS4148TE-11 Rohm Semiconductor RLS4148TE-11 label picture RLS4148TE-11 label picture 2 RLS4148TE-11 real image
RLS4148TE-11 Rohm Semiconductor RLS4148TE-11 label picture RLS4148TE-11 label picture 2 RLS4148TE-11 real image
Same model may have multiple batches, images only for reference.

RLS4148TE-11

Part No RLS4148TE-11
Manufacturer Rohm Semiconductor
Catalog Diodes, Rectifiers - Single
Description DIODE GEN PURP 75V 150MA LLDS
Datasheet
RLS4148TE-11 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Rohm Semiconductor
Packaging Reel - TR
Status Obsolete(EOL)
Diode Type Standard
Voltage - DC Reverse (Vr) (Max) 75V
Current - Average Rectified (Io) 150mA
Voltage - Forward (Vf) (Max) @ If 1V @ 10mA
Reverse Recovery Time (trr) 4ns
Current - Reverse Leakage @ Vr 5μA @ 75V
Capacitance @ Vr, F 4pF @ 0V, 1MHz
Mounting SMD (SMT)
Case / Package LLDS
Operating Temperature - Junction -65°C to 200°C
Win Source Part Number 096266-RLS4148TE-11
Family Name RLS4148
Introduction Date April 03, 2000
Halogen Free Compliant
Estimated EOL Date Obsolete
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian RLS4148TE-11 CAD Model

Description

The RLS4148TE-11 by Rohm Semiconductor is a standard diode type electronic component that has a voltage rating of up to 75V and an average rectified current of 150mA.

  • Mounting: This SMD (SMT) mounted diode
  • Forward Voltage: 1V @ 10mA
  • Reverse Recovery Time: 4ns
  • Capacitance: 4pF @ 0V and 1MHz
  • Reverse Leakage Current: 5μA @ 75V
  • Family: This component is part of the RLS4148 family
  • Category: discrete semiconductor products
  • Status: It is obsolete (EOL)
  • Case/Package: LLDS
  • Alternative Parts: GL34B, EGL34B, GL34BHE3/48
  • Introduction Date: April 03, 2000
  • Popularity: high popularity
