Products specifications

Manufacturer Rohm Semiconductor
Packaging Reel
Diode Type Standard
Voltage - DC Reverse (Vr) (Maximum) 200V
Current - Average Rectified (Io) 3A
Voltage - Forward (Vf) (Maximum) at If 930mV at 3A
Speed Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) 25ns
Current - Reverse Leakage at Vr 10μA at 200V
Mounting Style SMD
Manufacturer Package TO-252-3, DPak (2 Leads + Tab), SC-63
Supplier Device Package TO-252GE
Operating Temperature - Junction 150°C (Maximum)
Manufacturer Pack Quantity 2,500
MSL Level 1 (Unlimited)
Popularity Medium
Supply and Demand Status Balance
Win Source Part Number 806054-RF301BGE2STL
Ultra Librarian 3D Model Ultra Librarian RF301BGE2STL CAD Model

Description

The Rohm Semiconductor 806054-RF301BGE2STL is a fast recovery diode with a maximum voltage of 200V and a maximum average rectified current of 3A.

  • Reverse Recovery Time: 25ns
  • Forward Voltage: 930mV @ 3A
  • Package: TO-252-3, DPak (2 Leads + Tab), SC-63
  • Mounting: SMD
