Products specifications

Category Integrated Circuits (ICs) - Power Management (PMIC) - LED Drivers
Mfr Rohm Semiconductor
Series Automotive, AEC-Q100
Package Tape & Reel
Type DC DC Controller
Topology Step-Down (Buck) , Step-Up (Boost)
Internal Switch(s) No
Number of Outputs 4
Voltage - Supply (Min) 4.5V
Voltage - Supply (Max) 35V
Voltage - Output 40V
Current - Output / Channel 120mA
Frequency 200kHz ~ 2.2MHz
Dimming PWM
Applications Automotive
Temperature Range - Operating -40°C ~ 125°C (TA)
Mounting Type Surface Mount
Package / Case 28-VSSOP (0.173", 4.40mm Width) Exposed Pad
Supplier Device Package 28-HTSSOP-B
Base Product Number BD81A74
Standard Package 2,500
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 1345679-BD81A74EFV-ME2
Ultra Librarian 3D Model Ultra Librarian BD81A74EFV-ME2 CAD Model

Description

The BD81A74EFV-ME2 is a DC DC controller used for LED drivers and manufactured by Rohm Semiconductor.

  • Topology: Step-down (buck) and step-up (boost)
  • Outputs: Four
  • Dimming Option: PWM
  • Voltage Output: 40V
  • Current Output/Channel: 120mA
  • Temperature Range: -40°C to 125°C
  • Voltage Supply Range: 4.5V to 35V
  • Package Type: 28-VSSOP (0.173", 4.40mm Width) Exposed Pad
  • Application: Automotive
