The R3130N26EC-TR-F is a voltage detector IC manufactured by Ricoh. It's designed to monitor the supply voltage and issue a reset signal when the voltage drops below a specified threshold, ensuring stable operation of the connected system.

Applications

• Microcontroller reset circuits
• Power management in battery-powered devices
• Voltage monitoring in industrial equipment
• Consumer electronics
• System-on-Chip (SoC) voltage supervision

Features

• High-accuracy detection voltage: Provides precise monitoring of the supply voltage, ensuring reliable reset triggering.
• Low supply current: Minimizes power consumption, making it suitable for battery-operated applications.
• Built-in hysteresis: Prevents oscillations and chattering near the threshold voltage, ensuring a stable reset signal.
• Small package: Available in compact packages like SOT-23, saving valuable board space.
• Open-drain output: Allows for flexible connection to various microcontrollers and logic circuits.

Benefits

• Prevents system malfunction: By resetting the microcontroller when the voltage drops too low, it prevents data corruption and ensures proper system startup.
• Ensures data integrity: Protects against data loss and corruption caused by unstable voltage levels.
• Extends battery life: Low current consumption maximizes battery life in portable devices.
• Simplifies circuit design: Reduces the need for external components and complex voltage monitoring circuits.
• Improves system reliability: Provides a reliable and consistent reset signal, enhancing the overall stability of the system.

Additional Details

The R3130N26EC-TR-F has a detection voltage of 2.6V. It typically comes in a SOT-23 package for surface mount assembly. The 'TR' designation indicates tape and reel packaging for automated assembly. The operating temperature range is generally specified between -40°C and +85°C. The open-drain output requires a pull-up resistor. Consult the datasheet for specific electrical characteristics, timing diagrams, and application notes. The built-in hysteresis prevents false triggering due to noise or slight voltage fluctuations. Proper decoupling capacitors should be placed close to the device to minimize noise and ensure stable operation. This IC is suitable for various applications where reliable voltage monitoring and reset functionality are critical. The low quiescent current is particularly beneficial in battery-powered and energy-sensitive applications.
