RT8566GCP

Name: RT8566GCP
Brand: Richtek USA Inc.
SKU: 726547
Availability: InStock
Rating: 4.85 (48 reviews)

Get a Quote

Part No	RT8566GCP
Manufacturer	Richtek USA Inc.
Catalog	PMIC - LED Drivers
Description	IC LED DRVR RGLTR PWM 28TSSOP
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Integrated Circuits (ICs) - Power Management (PMIC) - LED Drivers
Mfr	Richtek USA Inc.
Package	Tape & Reel
Product Status	Active
Type	DC DC Regulator
Topology	Step-Up (Boost)
Internal Switch(s)	Yes
Number of Outputs	8
Voltage - Supply (Min)	9V
Voltage - Supply (Max)	28V
Voltage - Output	45V
Current - Output / Channel	120mA
Frequency	100kHz ~ 1MHz
Dimming	PWM
Applications	Backlight
Temperature Range - Operating	-40°C ~ 85°C (TA)
Mounting Type	Surface Mount
Package / Case	28-TSSOP (0.173", 4.40mm Width) Exposed Pad
Supplier Device Package	28-TSSOP-EP
Base Product Number	RT8566
Standard Package	2,500 pcs
MSL Level	3 (168 Hours)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8542.39.0001
Win Source Part Number	726547-RT8566GCP
Ultra Librarian 3D Model	Ultra Librarian RT8566GCP CAD Model

Alternative Products

Description

The RT8566GCP is a LED driver from Richtek USA Inc. It is designed for power management applications, specifically backlighting. This DC-DC regulator operates with a voltage output of 45V and a frequency range of 100kHz to 1MHz.

Voltage Output: 45V
Frequency Range: 100kHz to 1MHz
Current Output: 120mA per channel
Topology: step-up (boost)
Outputs: Eight
Dimming: PWM
Package: 28-TSSOP (0.173", 4.40mm Width) Exposed Pad
Operating Temperature: -40°C to 85°C
Quantity: 2,500 pcs
