RF2494 Real Image
Same model may have multiple batches, images only for reference.

RF2494

Part No RF2494
Manufacturer RF Micro Devices
Catalog Coaxial Connectors (RF)
Description CONN HDBNC JACK STR 75 OHM PCB
Datasheet
RF2494 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Connectors, Interconnects
Manufacturer Amphenol RF Division
Packaging Bulk
Status Active
Connector Style BNC, HD
Connector Type Jack, Female Socket
Contact Termination Solder
Shield Termination Solder
Impedance 75 Ohm
Mounting Through Hole
Fastening Type Bayonet Lock
Maximum Input Frequency 18GHz
Housing Color Gold
Body Material Brass
Body Finish Gold
Center Contact Plating Gold
Dielectric Material Polytetrafluoroethylene (PTFE)
Temperature Range - Operating -65°C to 165°C
Center Contact Material Beryllium Copper
Mating Cycles 500
Win Source Part Number 293399-RF2494
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian RF2494 CAD Model

Description

The Amphenol RF Division 293399-RF2494 is a BNC, HD style jack female socket connector with a bayonet lock fastening type.

  • Housing Color: gold
  • Body Material: brass
  • Impedance: 75 Ohm
  • Contact Termination: solder
  • Mounting: through hole
  • Maximum Input Frequency: 18GHz
  • Temperature Range: -65°C to 165°C
  • Operating: operating
  • Popularity: medium
  • Supply and Demand Status: limited
  • Manufacturer: Amphenol RF Division
