RF2310 Real Image
Same model may have multiple batches, images only for reference.

RF2310

Part No RF2310
Manufacturer RF Micro Devices
Catalog Coaxial Cables (RF)
Description AMMC RA PLG-PLG .81MM CBL 100MM
Datasheet
RF2310 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Cable Assemblies
Manufacturer Amphenol RF Division
Status Active
Gender Female to Female
Style AMMC to AMMC
1st Connector Ultra Miniature Coaxial Plug Female Socket, Right Angle
2nd Connector Ultra Miniature Coaxial Plug Female Socket, Right Angle
Length 3.937" (100.00mm)
Cable Type 0.81mm OD Coaxial Cable
Impedance 50 Ohm
Maximum Input Frequency 6GHz
Color Black
Features Shielded
Temperature Range - Operating -40°C to 90°C
Win Source Part Number 293317-RF2310
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian RF2310 CAD Model

Description

The Amphenol RF Division's RF2310 cable assembly is a shielded, ultra-miniature coaxial plug female socket, right-angle style with a length of 3.937" (100.00mm).

  • Cable Type: 0.81mm OD coaxial cable
  • Impedance: 50 Ohm
  • Maximum Input Frequency: 6GHz
  • Color: Black
  • Connector Type: Two ultra-miniature coaxial plug female sockets, both right-angled
  • Supply and Demand Status: Balanced
