The Pulse PE-62916NL is a surface-mount Ethernet transformer designed for 10/100/1000Base-T applications. It provides electrical isolation and impedance matching, crucial for reliable data transmission in Ethernet networks. Compliant with IEEE 802.3 standards, this transformer is commonly used in network interface cards (NICs), routers, switches, and other networking devices.

Applications

• Gigabit Ethernet Network Interface Cards (NICs)
• Routers and Switches
• Embedded Systems with Ethernet Connectivity
• Industrial Control Systems
• Networked Storage Devices (NAS)

Features

• Supports 10/100/1000Base-T Ethernet
• Compliant with IEEE 802.3 Standards
• Provides Electrical Isolation (Typically 1500 Vrms)
• Impedance Matching for Optimal Signal Transmission
• Surface Mount Package for Automated Assembly
• Compact Size for Space-Constrained Applications

Benefits

• Ensures reliable high-speed data transmission over Ethernet.
• Protects network devices from voltage surges and ground loops.
• Minimizes signal reflections and distortions.
• Simplifies board layout and assembly.
• Reduces electromagnetic interference (EMI).
• Enhances system performance and stability.

Additional Details

The PE-62916NL Ethernet transformer features a typical isolation voltage of 1500 Vrms, providing a safety barrier between the network and the connected device. It is designed to operate within a temperature range of 0°C to 70°C. Its construction minimizes insertion loss and maximizes return loss, ensuring signal integrity. The surface-mount package is suitable for automated assembly processes, reducing manufacturing costs. The transformer is lead-free and RoHS compliant, meeting environmental regulations. The specific inductance and turns ratio are designed to match the impedance requirements of Gigabit Ethernet PHY chips.
