TNY276PN

Part No TNY276PN
Manufacturer Power Integrations
Catalog PMIC - AC DC Converters, Offline Switchers
Description IC OFFLINE SWIT OVP OTP HV 8DIP / AC to DC Switching Converter Off-Line Switcher 140kHz 7-Pin PDIP-C
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Power Integrations
Packaging Tube/Rail
Status Active
Output Isolation Isolated
Internal Switch(s) Yes
Voltage - Breakdown 700V
Topology Flyback
Duty Cycle 65%
Frequency - Switching 132kHz
Power (Watts) 19W
Fault Protection Current Limiting, Open Loop, Over Temperature, Over Voltage, Short Circuit
Control Features EN
Temperature Range - Operating -40°C to 150°C (TJ)
Case / Package DIP-8C
Mounting Through Hole
Win Source Part Number 092448-TNY276PN
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Family Name TNY276
Introduction Date January 09, 2007
ECCN EAR99
Country of Origin China
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian TNY276PN CAD Model

Description

This electronic component is manufactured by Power Integrations with a Win Source Part Number of 092448-TNY276PN.

  • Win Source Part Number: 092448-TNY276PN
  • Type: Active Integrated Circuit
  • Topology: Flyback
  • Output Isolation: Isolated
  • Internal Switch: Yes
  • Voltage Breakdown: 700V
  • Duty Cycle: 65%
  • Frequency of Switching: 132kHz
  • Fault Protection: Current Limiting, Open Loop, Over Temperature, Over Voltage, Short Circuit
  • Control Feature: EN
  • Family: TNY276
  • Supply and Demand Status: Sufficient
