Same model may have multiple batches, images only for reference.

QH05TZ600

Name: QH05TZ600
Brand: Power Integrations
SKU: 658550
Availability: InStock
Rating: 4.91 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	QH05TZ600
Manufacturer	Power Integrations
Catalog	Diodes, Rectifiers - Single
Description	DIODE GEN PURP 600V 5A TO220AC
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Discrete Semiconductor Products - Diodes - Rectifiers - Single Diodes
Mfr	Power Integrations
Series	Qspeed™
Package	Tube
Product Status	Active
Technology	Standard
Voltage - DC Reverse (Vr) (Max)	600 V
Current - Average Rectified (Io)	5A
Voltage - Forward (Vf) (Max) @ If	3.1 V @ 5 A
Speed	Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr)	10 ns
Current - Reverse Leakage @ Vr	250 µA @ 600 V
Capacitance @ Vr, F	17pF @ 10V, 1MHz
Mounting Type	Through Hole
Package / Case	TO-220-2
Supplier Device Package	TO-220AC
Operating Temperature - Junction	150°C (Max)
Standard Package	50 pcs
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8541.10.0080
Win Source Part Number	658550-QH05TZ600
Ultra Librarian 3D Model	Ultra Librarian QH05TZ600 CAD Model

Alternative Products

Description

The QH05TZ600 is a fast recovery diode rectifier.

Series: Qspeed™
Reverse Voltage: 600V
Average Rectified Current: 5A
Recovery Time: 10ns
Reverse Leakage Current: 250µA @ 600V
Capacitance: 17pF @ 10V and 1MHz
Maximum Junction Temperature: 150°C
Mounting: Through hole
Package: TO-220-2
ECCN: EAR99
REACH: Unaffected
