LNK564DG-TL Real Image LNK564DG-TL real image10436
Same model may have multiple batches, images only for reference.
LNK564DG-TL Real Image LNK564DG-TL real image10436
LNK564DG-TL Real Image LNK564DG-TL real image10436
Same model may have multiple batches, images only for reference.

LNK564DG-TL

Part No LNK564DG-TL
Manufacturer Power Integrations
Catalog PMIC - AC DC Converters, Offline Switchers
Description IC OFFLINE SWIT OTP HV 8SOP
Datasheet
LNK564DG-TL Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Power Integrations
Packaging Reel - TR
Status Active
Output Isolation Isolated
Internal Switch(s) Yes
Voltage - Breakdown 700V
Topology Flyback
Duty Cycle 70%
Frequency - Switching 100kHz
Power (Watts) 3W
Fault Protection Current Limiting, Open Loop, Over Temperature, Short Circuit
Control Operating Temperature -40°C to 150°C (TJ)
Case / Package SO-8C
Mounting Surface Mount
Win Source Part Number 1055995-LNK564DG-TL
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian LNK564DG-TL CAD Model

Description

The Power Integrations LNK564DG-TL integrated circuit is a high-performance power supply solution that is ideal for flyback topologies.

  • Power Output: 3W
  • Voltage Breakdown: 700V
  • Designed to: Deliver reliable and efficient power supply for various applications.
  • Supply and Demand Status: Balance
  • Manufacturer: Power Integrations
