The DD78S10000 is a D-Sub Connector Assembly manufactured by Positronic.

• Product Name: DD78S10000
• Connector Type: D-Sub Connector Assembly
• RoHS Compliant: Non-Compliant
• Win Source Part Number: 1340870-DD78S10000
• Color: Blue
• Gender: Receptacle, Female Socket
• Number of Positions: 78
• Contact Type: Signal
• Number of Rows: Four
• Termination: Crimp
• Contact Finish: Gold
• Contact Finish Thickness: Flash
• Package: Box
• Contact Form: Machined
• Wire Gauge: 22-30 AWG
• Contact Material: Copper Alloy
• Connector Style: D-Sub, High Density
• Voltage Rating: 300V
• Ingress Protection: IP65/IP67 (Dust Tight, Water-Resistant, Waterproof)
• Material Flammability Rating: UL94 V-0
• Shell Material/Finish: Steel, Clear Chromate Plated Zinc
• Dielectric Material: Polyester, Glass-Filled
• Shell Size Connector Layout: 5 (DD, D) High Density
• Mounting Type: Free Hanging (In-Line)
• Operating Temperature: -55°C to 125°C
