The PAW3201DH is an optical mouse sensor from Pixart Imaging Inc., designed for use in a variety of mouse applications. It utilizes advanced optical tracking technology to provide precise and reliable cursor control. This sensor is engineered for low power consumption, making it suitable for both wired and wireless mouse designs.

Applications:

• Wired optical mice
• Wireless optical mice
• Gaming mice
• Office mice
• Trackballs

Features:

• High-performance optical tracking engine
• Low power consumption for extended battery life in wireless applications
• Self-adjusting frame rate
• Built-in oscillator
• Motion detection with high speed capabilities (refer to datasheet for specific values)
• Compact package

Benefits:

• Provides accurate and responsive cursor control
• Prolongs battery life in wireless mice
• Offers reliable tracking performance on a variety of surfaces
• Simplifies mouse design with its integrated functions
• Reduces system costs with fewer external components
• Improves user experience with smooth and precise movement

Additional Details:

The PAW3201DH works by illuminating a surface with an LED and capturing an image of the surface with an internal sensor. The sensor then processes the image to determine the direction and amount of movement. This information is then transmitted to the host system for cursor control.

Specifications (Typical):

• Resolution: Consult datasheet for specific value (e.g., 1000 DPI, 1600 DPI)
• Supply Voltage: Consult datasheet for specific value (e.g., 5V)
• Power Consumption: Consult datasheet for specific value (e.g., in the low mA range)
• Operating Temperature: Consult datasheet for specific value
• Package Type: Consult datasheet for specific value
