1714912 Real Image
Same model may have multiple batches, images only for reference.

1714912

Part No 1714912
Manufacturer Phoenix Contact
Catalog Rectangular Connectors
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Male Pins
Mfr Phoenix Contact
Series COMBICON FP
Package Tape & Reel
Connector Type Header
Contact Type Male Pin
Pitch - Mating 0.050" (1.27mm)
Number of Positions 12
Number of Rows 2
Row Spacing - Mating 0.050" (1.27mm)
Number of Positions Loaded All
Style Board to Board or Cable
Shrouding Shrouded - 4 Wall
Mounting Type Surface Mount, Right Angle
Termination Solder
Fastening Type Push-Pull
Contact Length - Mating 0.157" (4.00mm)
Insulation Height 0.165" (4.20mm)
Contact Shape Rectangular
Contact Finish - Mating Gold
Contact Material Copper Alloy
Insulation Material Liquid Crystal Polymer (LCP)
Features Board Guide, Solder Retention
Temperature Range - Operating -55°C ~ 125°C
Material Flammability Rating UL94 V-0
Insulation Color Black
Current Rating (Amps) 1.4A
Voltage Rating 500V
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.69.4040
Win Source Part Number 1315041-1714912
Ultra Librarian 3D Model Ultra Librarian 1714912 CAD Model

Description

Phoenix Contact COMBICON FP 1315041-1714912 is a 12-position male pin header.

  • Features: Board Guide, Solder Retention
  • Fastening Type: Push-Pull
  • Connector Type: Header
  • Contact Type: Male Pin
  • Wire Gauge: 12-26 AWG
  • Voltage Rating: 500V
  • Contact Material: Copper Alloy
  • Insulation Material: Liquid Crystal Polymer (LCP)
  • Contact Finish: Gold
  • Insulation Color: Black
  • Board/Cable Style: Board to Board or Cable
  • Pitch-Mating: 0.050" (1.27mm)
  • Row Spacing-Mating: 0.050" (1.27mm)
  • Mounting Type: Surface Mount, Right Angle
  • Shrouding: Shrouded-4 Wall
  • ECCN: EAR99
  • HTSUS: 8536.69.4040
