HC2E-H-DC48V-F Real Image
Same model may have multiple batches, images only for reference.

HC2E-H-DC48V-F

Part No HC2E-H-DC48V-F
Manufacturer Panasonic
Catalog Power Relays, Over 2 Amps
Description RELAY GEN PURPOSE DPDT 3A 48V
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Relays
Manufacturer Panasonic Electric Works
Packaging Bulk
Status Active
Relay Type General Purpose
Coil Type Non Latching
Coil Current 18.5mA
Coil Voltage 48VDC
Contact Form DPDT (2 Form C)
Contact Rating (Current) 3A
Switching Voltage 250VAC - Max
Turn On Voltage (Max) 38.4 VDC
Turn Off Voltage (Min) 4.8 VDC
Operate Time 10ms
Release Time 5ms
Features Sealed - Amber
Mounting Socketable
Termination Style Plug In
Coil Power 900 mW
Coil Resistance 2.6 kOhms
Temperature Range - Operating -40°C to 60°C
Win Source Part Number 001498-HC2E-H-DC48V-F
Popularity Medium
Supply and Demand Status Limited
Quantity per package 20
Ultra Librarian 3D Model Ultra Librarian HC2E-H-DC48V-F CAD Model

Description

The HC2E-H-DC48V-F is a DPDT (2 Form C) sealed relay from Panasonic Electric Works.

  • Coil Voltage: 48VDC
  • Coil Resistance: 2.6 kOhms
  • Coil Current: 18.5mA
  • Relay Type: General Purpose
  • Coil Type: Non-Latching
  • Contact Rating (Current): 3A
  • Switching Voltage: 250VAC - Max
  • Turn-On Voltage (Max): 38.4 VDC
  • Turn-Off Voltage (Min): 4.8 VDC
  • Release Time: 5ms
  • Coil Power: 900 mW
  • Packaging: Bulk
  • Termination Style: Plug-In
  • Features: Socketable, Sealed - Amber
  • Supply and Demand Status: Limited
  • Quantity per Package: 20
