ESB-30B102 Panasonic – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Mounting Type Through Hole
Type Standard
Circuit DPDT
Switch Function On-On
Current Rating (Amps) 200mA (DC)
Voltage Rating - DC 14 V
Actuator Type Plunger for Cap
Actuator Marking No Marking
Color - Actuator/Cap Gray
Termination Style PC Pin
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1563617-ESB-30B102
Ultra Librarian 3D Model Ultra Librarian ESB-30B102 CAD Model
