The ELL-6UH100M is a 10 µH shielded wirewound power inductor from Panasonic with a rated current of 1.8 A and a DC resistance of 63 mΩ. It is a surface mount device (SMD) with a 6 x 6 x 5 mm footprint. The ELL-6UH100M is designed for use in a wide range of applications, including power supplies, DC-DC converters, and motor drives.

Features

• Shielded construction to reduce EMI
• High current rating of 1.8 A
• Low DC resistance of 63 mΩ
• Compact 6 x 6 x 5 mm footprint
• Wide operating temperature range of -40°C to +125°C

Applications

• Power supplies
• DC-DC converters
• Motor drives
• Industrial electronics
• Automotive electronics
• Consumer electronics

Benefits

The ELL-6UH100M power inductor offers a number of benefits, including:

• High efficiency: The low DC resistance of the ELL-6UH100M helps to improve the efficiency of power circuits.
• Reduced EMI: The shielded construction of the ELL-6UH100M helps to reduce electromagnetic interference (EMI), which can improve the performance of electronic equipment.
• Compact size: The small footprint of the ELL-6UH100M makes it ideal for space-constrained applications.
• Wide operating temperature range: The ELL-6UH100M can operate in a wide range of temperatures, making it suitable for a variety of environments.

Specifications

• Inductance: 10 µH
• Rated current: 1.8 A
• DC resistance: 63 mΩ
• Operating temperature range: -40°C to +125°C
• Footprint: 6 x 6 x 5 mm

Conclusion

The ELL-6UH100M power inductor from Panasonic is a high-quality, reliable component that is well-suited for a wide range of applications. It offers a number of benefits, including high efficiency, reduced EMI, a compact size, and a wide operating temperature range.
