Same model may have multiple batches, images only for reference.

EEA-GA1HR22H

Name: EEA-GA1HR22H
Brand: Panasonic
SKU: 764080
Availability: InStock
Rating: 4.91 (5 reviews)

Get a Quote

Part No	EEA-GA1HR22H
Manufacturer	Panasonic
Catalog	Aluminum Capacitors
Description	CAP ALUM 0.22UF 20% 50V RADIAL
Datasheet	EEA-GA1HR22H Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Capacitors
Manufacturer	Panasonic Electronic Components
Series	GA
Packaging	Tape in Box
Part Status	Obsolete(EOL)
Capacitance	0.22μF
Tolerance	±20%
Voltage Rating	50V
Lifetime @ Temp.	1000 Hrs @ 105°C
Operating Temperature Range	-55°C ~ 105°C
Polarization	Polar
Applications	General
Ripple Current - Low Frequency	2.3mA @ 120Hz
Ripple Current - High Frequency	3.565mA @ 100kHz
Lead Spacing	0.098" (2.50mm)
Dimension	0.157" Dia (4.00mm)
Height - Seated (Maximum)	0.276" (7.00mm)
Mounting Style	Through Hole
Package	Radial, Can
Win Source Part Number	764080-EEA-GA1HR22H
Popularity	Medium
Supply and Demand Status	Balance
Ultra Librarian 3D Model	Ultra Librarian EEA-GA1HR22H CAD Model

Alternative Products

Description

The Panasonic Electronic Components EEA-GA1HR22H is an obsolete(EOL) capacitor from the Panasonic Electronic Components GA series.

Capacitance: 0.22μF
Tolerance: ±20%
Voltage Rating: 50V
Package: Radial, Can
Mounting Style: Through Hole
Dimensions: 0.157" Dia (4.00mm)
Height Seated (Maximum): 0.276" (7.00mm)
Ripple Current (Low Frequency): 2.3mA @ 120Hz
Ripple Current (High Frequency): 3.565mA @ 100kHz
Lifetime at Temperature: 1000 Hrs @ 105°C
Polarization: Polar
