Same model may have multiple batches, images only for reference.
ECC-T3F150JG2 Real Image
Same model may have multiple batches, images only for reference.

ECC-T3F150JG2

Part No ECC-T3F150JG2
Manufacturer Panasonic
Catalog Ceramic Capacitors
Description CAP CER 15PF 3KV SL/GP SMD
Datasheet
ECC-T3F150JG2 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Capacitors
Manufacturer Panasonic Electronic Components
Packaging Reel - TR
Status Obsolete(EOL)
Capacitance 15pF
Tolerance ±5%
Voltage Rating 3000V (3kV)
Temperature Coefficient SL/GP
Temperature Range - Operating -25°C to 105°C
Features High Voltage
Applications General Purpose
Mounting Surface Mount, MLCC
Dimension 0.224" L x 0.177" W (5.70mm x 4.50mm)
Thickness (Max) 0.091" (2.30mm)
Win Source Part Number 124767-ECC-T3F150JG2
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian ECC-T3F150JG2 CAD Model

Description

Description

The ECC-T3F150JG2 is an advanced electronic capacitor with greater capacitance, perfect for applications requiring more substantial energy storage.

Features and Benefits

  • High energy density
  • Exceptional thermal performance
  • Low leakage current
  • Long operational life

Applications

  • Uninterruptible power supplies (UPS)
  • Switch-mode power supplies
  • Audio/visual equipment
  • Aerospace applications

Additional Details

The ECC-T3F150JG2's capabilities make it a standout choice for applications where efficiency and longevity are critical.
