DSBT2-S-DC12V Nais(Matsushita Electric Works)
Same model may have multiple batches, images only for reference.

DSBT2-S-DC12V

Part No DSBT2-S-DC12V
Manufacturer Panasonic
Catalog Signal Relays, Up to 2 Amps
Description RELAY GEN PURPOSE DPDT 2A 12VDC / General Purpose Relay DPDT (2 Form C) Through Hole
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Relays - Signal Relays, Up to 2 Amps
Mfr Panasonic
Series DS-BT
Package Tube
Product Status Obsolete
Mounting Type Through Hole
Coil Voltage 12VDC
Contact Form DPDT (2 Form C)
Contact Rating (Current) 2 A
Switching Voltage 250VAC, 220VDC - Max
Coil Current 30 mA
Coil Type Non Latching
Termination Style PC Pin
Must Operate Voltage 9 VDC
Must Release Voltage 1.2 VDC
Operate Time 3 ms
Release Time 2 ms
Temperature Range - Operating -40°C ~ 70°C
Contact Material Silver (Ag), Gold (Au)
Relay Type General Purpose
Coil Resistance 400 Ohms
Base Product Number DSBT2-S
Standard Package 25 pcs
Moisture Sensitivity Level (MSL) 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.41.0020
Win Source Part Number 587110-DSBT2-S-DC12V
Ultra Librarian 3D Model Ultra Librarian DSBT2-S-DC12V CAD Model

Description

The DSBT2-S-DC12V from the DS-BT series from Panasonic is a signal relay with a compact design and high switching capabilities.

  • Termination Style: PC Pin
  • Contact Form: DPDT (2 Form C)
  • Contact Material: Silver (Ag) and Gold (Au)
  • Coil Voltage: 12VDC
  • Coil Resistance: 400 Ohms
  • Contact Rating: 2A
  • Maximum Switching Voltage (AC): 250VAC
  • Maximum Switching Voltage (DC): 220VDC
  • Operate Time: 3ms
  • Release Time: 2ms
  • Mounting Type: Through-Hole
  • Packaging: Tube (25 pcs)
