AV34043-A Real Image
Same model may have multiple batches, images only for reference.

AV34043-A

Part No AV34043-A
Manufacturer Panasonic
Catalog Snap Action, Limit Switches
Description SWITCH SNAP ACTION SPDT 3A 125V / Switch SPDT Through Hole
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Switches>Limit Switches
Mfr Panasonic Electric Works
Series AV3
Package Tube
Circuit SPDT
Switch Function On-Mom
Current Rating (Amps) 3A (AC/DC)
Voltage Rating - AC 125 V
Voltage Rating - DC 30 V
Actuator Type Round (Pin Plunger)
Mounting Type Through Hole
Termination Style PC Pin
Operating Force 100gf
Release Force 15gf
Pretravel 0.024" (0.6mm)
Differential Travel 0.004" (0.1mm)
Overtravel 0.015" (0.4mm)
Temperature Range - Operating -25°C ~ 85°C
Operating Position 0.330" (8.4mm)
Electrical Life 50,000 Cycles
Mechanical Life 500,000 Cycles
Base Product Number AV34043
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.50.7000
Other Names -AV34043
Standard Package 100
Win Source Part Number 963673-AV34043-A
Ultra Librarian 3D Model Ultra Librarian AV34043-A CAD Model

Description

The AV3 series limit switch from Panasonic Electric Works is a highly reliable switch that is designed to operate in a variety of applications.

  • Circuit: SPDT
  • Switch Function: On-Mom
  • Actuator Type: Round Pin Plunger
  • Electrical Life: 50,000 cycles
  • Mounting Type: Through-Hole
  • Termination Style: PC Pin
  • Voltage Rating: 125 VAC / 30 VDC
  • Current Rating: 3A (AC/DC)
  • Operating Force: 100gf
  • Mechanical Life: 500,000 cycles
  • Release Force: 15gf
  • Pretravel: 0.024 inches (0.6mm)
  • Differential Travel: 0.004 inches (0.1mm)
  • Overtravel: 0.015 inches (0.4mm)
  • Operating Position: 0.330 inches (8.4mm)
  • Operating Temperature Range: -25°C to 85°C
