AQY211G2SX Panasonic AQY211G2SX Real Image AQY211G2SX real image AQY211G2SX real image21515 AQY211G2SX real image21516 AQY211G2SX Real Image
Same model may have multiple batches, images only for reference.
AQY211G2SX Panasonic AQY211G2SX Real Image AQY211G2SX real image AQY211G2SX real image21515 AQY211G2SX real image21516 AQY211G2SX Real Image
AQY211G2SX Panasonic AQY211G2SX Real Image AQY211G2SX real image AQY211G2SX real image21515 AQY211G2SX real image21516 AQY211G2SX Real Image
Same model may have multiple batches, images only for reference.

AQY211G2SX

Part No AQY211G2SX
Manufacturer Panasonic
Catalog Solid State Relays
Description RELAY OPTO SPST-NO 1.6A 4SOP / Solid State Relay 50mA 1.5V DC-IN 1.6A 40V AC/DC-OUT 4-Pin SOP T/R
Datasheet
AQY211G2SX Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Relays
Manufacturer Panasonic Electric Works
Series PhotoMOS AQY
Packaging Reel package
Circuit SPST-NO (1 Form A)
Output Type AC, DC
On-State Resistance (Maximum) 150 mOhm
Load Current 1.6A
Voltage - Input 1.32VDC
Voltage - Load 0 ~ 40 V
Mounting SMD
Termination Style Gull Wing
Package 4-SOP (0.173", 4.40mm)
Manufacturer Package 4-SOP
Relay Type Relay
Win Source Part Number 768761-AQY211G2SX
Popularity Medium
Supply and Demand Status Balance
Quantity per package 1k pcs
Family Name AQY211
Introduction Date August 06, 2012
ECCN EAR99
Estimated EOL Date 2029
Ultra Librarian 3D Model Ultra Librarian AQY211G2SX CAD Model

Description

The Panasonic Electric Works PhotoMOS AQY series relay, with the part number 768761-AQY211G2SX, is a 4-SOP package relay with a gull wing termination style.

  • Circuit: SPST-NO (1 Form A)
  • Load Current: Up to 1.6A
  • Load Voltage: 0 to 40 V
  • On-State Resistance: 150 mOhm
  • Voltage Input: 1.32VDC
  • Output Types: AC and DC
