AQV252G2SX Real Image AQV252G2SX Real Image1 AQV252G2SX Real Image2
Same model may have multiple batches, images only for reference.
AQV252G2SX Real Image AQV252G2SX Real Image1 AQV252G2SX Real Image2
AQV252G2SX Real Image AQV252G2SX Real Image1 AQV252G2SX Real Image2
Same model may have multiple batches, images only for reference.

AQV252G2SX

Part No AQV252G2SX
Manufacturer Panasonic
Catalog Solid State Relays
Description SSR RELAY SPST-NO 3A 0-50V / Solid State SPST-NO (1 Form A) 6-SOP (0.173", 4.40mm)
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Relays - Solid State Relays
Mfr Panasonic
Series PhotoMOS™ AQV
Package Tape & Reel
Product Status Active
Mounting Type Surface Mount
Circuit SPST-NO (1 Form A)
Output Type AC, DC
Voltage - Input 1.14VDC
Voltage - Load 0 V ~ 50 V
Load Current 3 A
On-State Resistance (Max) 70 mOhms
Termination Style Gull Wing
Package / Case 6-SOP (0.173", 4.40mm)
Supplier Device Package 6-SOP
Base Product Number AQV252
Standard Package 1,000 pcs
ECCN EAR99
HTSUS 8536.41.0030
Win Source Part Number 848459-AQV252G2SX
Ultra Librarian 3D Model Ultra Librarian AQV252G2SX CAD Model

Description

The Panasonic PhotoMOS™ AQV series is a reliable and versatile solid-state relay designed for various applications.

  • Series: PhotoMOS™ AQV
  • Manufacturer: Panasonic
  • Termination Style: gull wing
  • Package: 6-SOP
  • Mounting: surface mountable
  • Packaging: tape & reel
  • Voltage Input: 1.14VDC
  • Output Types: AC and DC
  • Circuit Configuration: SPST-NO (1 Form A)
  • Maximum On-State Resistance: 70 mOhms
  • Load Current: 3 A
  • Status: active
  • Standard Package: 1,000 pcs
