AS1506-BTDT-10 ams AS1506-BTDT-10 real image AS1506-BTDT-10 label picture
Same model may have multiple batches, images only for reference.
AS1506-BTDT-10 ams AS1506-BTDT-10 real image AS1506-BTDT-10 label picture
AS1506-BTDT-10 ams AS1506-BTDT-10 real image AS1506-BTDT-10 label picture
Same model may have multiple batches, images only for reference.

AS1506-BTDT-10

Part No AS1506-BTDT-10
Manufacturer OSRAM Opto Semiconductors Inc.
Catalog Data Acquisition - Digital Potentiometers
Description IC DGTL POT 10KOHM 256TAP 8TDFN
Datasheet
AS1506-BTDT-10 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Data Acquisition - Digital Potentiometers
Mfr OSRAM Opto Semiconductors Inc.
Package Tape & Reel
Product Status Obsolete
Programmable Not Verified
Taper Linear
Configuration Potentiometer
Number of Circuits 1
Number of Taps 256
Resistance (Ohms) 10k
Interface SPI
Memory Type Non-Volatile
Voltage - Supply 2.7V ~ 5.5V
Tolerance ±25%
Temperature Coefficient (Typ) 90ppm/°C
Mounting Type Surface Mount
Supplier Device Package 8-TDFN (3x3)
Package / Case 8-WDFN Exposed Pad
Temperature Range - Operating -40°C ~ 85°C
Resistance - Wiper (Ohms) (Typ) 200
Standard Package 1,000 pcs
Moisture Sensitivity Level (MSL) 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 564581-AS1506-BTDT-10
Ultra Librarian 3D Model Ultra Librarian AS1506-BTDT-10 CAD Model

Description

The AS1506-BTDT-10 is a digital potentiometer from OSRAM Opto Semiconductors Inc.

  • Category: Integrated Circuits - Data Acquisition
  • Packaging: Tape and Reel
  • Standard Package: 1,000 pieces
  • Resistance: 10k Ohms
  • Tolerance: ±25%
  • Taper: Linear
  • Taps: 256
  • Interface: SPI
  • Voltage Range: 2.7V to 5.5V
  • Mounting: Surface Mountable
  • Package: 8-WDFN Exposed Pad
  • Operating Temperature: -40°C to 85°C
  • REACH: Unaffected
  • ECCN: EAR99
