Product Overview: TVS4201MR6T1G from ON Semiconductor

The TVS4201MR6T1G is a state-of-the-art transient voltage suppressor (TVS) diode designed by ON Semiconductor, a leading company in energy-efficient innovations. This robust TVS diode is engineered to protect sensitive electronic equipment from voltage spikes and transients induced by lightning and other transient voltage events.

Key Features

• Peak Pulse Power Dissipation: The device boasts an impressive 600W peak pulse power dissipation rating for a 10/1000μs waveform, ensuring reliable protection against high energy transients.
• Stand-off Voltage: With a stand-off voltage of 4201V, it provides a high level of protection for sensitive circuits without compromising performance.
• Low Leakage Current: It offers a low leakage current of less than 1μA, minimizing power loss and ensuring efficiency in standby or off modes.
• Fast Response Time: The TVS4201MR6T1G responds to overvoltage events in picoseconds, providing immediate protection for your electronic components.
• Bi-directional Clamping: The device features bi-directional clamping, making it ideal for AC applications or where the polarity of the transient could be either positive or negative.
• Package: Housed in a small, leadless SOD-123FL package, it offers a compact footprint that is suitable for high-density circuit board designs.
• Environmental Compliance: It is compliant with RoHS and Halogen-Free standards, making it an environmentally friendly choice for electronic designs.

Applications

The TVS4201MR6T1G is versatile and can be used in a wide range of applications. It is particularly suitable for protecting voltage-sensitive components in consumer electronics, portable devices, power supplies, and communication systems. Its robust design also makes it an excellent choice for industrial and automotive applications where reliability and protection from harsh electrical transients are critical.

Quality and Reliability

ON Semiconductor is committed to delivering high-quality products. The TVS4201MR6T1G is subject to rigorous testing and quality control measures to ensure that it meets the industry's highest standards for performance and reliability. With ON Semiconductor's expertise in circuit protection, you can trust the TVS4201MR6T1G to safeguard your electronic investments.
