The ON Semiconductor NL27WZ04DFT1G is a high-performance dual inverter designed for use in a wide range of electronic applications. This compact and efficient device belongs to the advanced high-speed CMOS family, offering a perfect blend of speed and power consumption, making it an ideal choice for portable and battery-powered products.

Key Features

• Logic Type: The NL27WZ04DFT1G features two independent inverters, providing flexibility in logic design and application.
• High-Speed Operation: It boasts a propagation delay time of approximately 2.6 ns, ensuring high-speed operation that is crucial for modern digital circuits.
• Low Power Consumption: With a typical low power consumption of 10 µA, this device is optimized for power-sensitive applications.
• Operating Voltage Range: The device operates over a broad voltage range of 1.65V to 5.5V, accommodating various power supply requirements and ensuring compatibility with both low-voltage and standard logic devices.
• Output Drive Capability: It can drive up to 24 mA at the outputs, allowing it to control a variety of peripheral components.
• Schmitt Trigger Action: Inputs include Schmitt triggers, which provide enhanced noise immunity and stable output switching.
• ESD Performance: The device is designed with input and output protection against electrostatic discharge, withstanding human body model (HBM) ESD events up to 2 kV.

Applications

The versatility of the ON Semiconductor NL27WZ04DFT1G makes it suitable for a diverse range of applications, including:

• Wave shaping and signal processing
• Logic level conversion
• Oscillator circuits
• High-speed data processing
• Battery-powered and portable devices

Package and Quality

The NL27WZ04DFT1G is offered in a compact SC-88A (SOT-353) package, which is not only space-saving but also conducive to efficient PCB layout. ON Semiconductor is committed to the highest standards of quality and reliability, ensuring that this dual inverter meets the stringent requirements of the industry for performance and durability.
