ON Semiconductor NL17SZ08DFT2G Logic Gate

The NL17SZ08DFT2G from ON Semiconductor is a high-performance, two-input AND gate that offers a compact and efficient solution for a wide range of digital logic applications. This device is part of ON Semiconductor's 1.65 V to 5.5 V HC/UH series, designed to operate with a low power supply while maintaining excellent speed and output drive.

Key Features:

• Wide Operating Voltage Range: It is designed to function over a broad voltage range of 1.65 V to 5.5 V, making it versatile for use in various circuit configurations and compatible with TTL levels.
• High-Speed Operation: The NL17SZ08DFT2G is capable of high-speed operation, with a typical propagation delay time of only 4.5 ns at a 5 V supply, ensuring quick and reliable logic operations.
• Low Power Consumption: This logic gate is optimized for low power consumption, which is critical for battery-powered and portable devices, helping to extend their operational life.
• Ultra-Small Package: The device comes in an ultra-small SC-88A/SOT-353 package, which is ideal for space-constrained applications, allowing for high-density PCB layouts.
• Output Drive Capability: It can drive up to 8 LSTTL loads, providing sufficient output current for most low-power logic applications.
• Multiple Logic Functions: By external connection, it can perform a variety of logic functions, offering flexibility in circuit design.

Applications:

The NL17SZ08DFT2G is suitable for a myriad of applications across different industries, including:

• Portable Devices
• Computing
• Data Communication
• Consumer Electronics
• Embedded Systems

Quality and Reliability:

ON Semiconductor is known for its commitment to quality, and the NL17SZ08DFT2G is no exception. It is designed and manufactured to meet the rigorous standards of the industry, ensuring reliable performance in even the most demanding environments.

Environmental Compliance:

The NL17SZ08DFT2G is compliant with the RoHS directive, highlighting ON Semiconductor's dedication to environmental sustainability and the reduction of hazardous substances in electronic components.
