ON Semiconductor NB100LVEP56MN: A High-Performance 2.5V / 3.3V ECL Differential Data and Clock D Flip−Flop

The NB100LVEP56MN from ON Semiconductor is a versatile and high-speed differential data and clock D flip−flop designed to operate with a 2.5V or 3.3V power supply. This advanced integrated circuit is part of ON Semiconductor's high-performance ECLinPS MAX™ family, offering a perfect solution for applications requiring fast edge rates and minimal skew.

Featuring differential clock (CLK, CLK) and data (D, D) inputs, this device is capable of handling high-speed data transmission with precision. The differential outputs (Q, Q) ensure reliable signal integrity, even in environments with considerable electrical noise. The NB100LVEP56MN also includes an asynchronous set (ASET, ASET) and reset (ARES, ARES) function, providing additional control and flexibility in system design.

Constructed with an advanced, proprietary bipolar process, the NB100LVEP56MN delivers exceptional performance with a maximum frequency of 3 GHz for clock operation. Its low skew and broad operating temperature range from -40°C to +85°C make it an ideal choice for a wide array of applications, including high-speed computing, telecommunication, and networking equipment.

The device is housed in a compact 32-pin QFN package, minimizing board space and simplifying PCB design. The package is also RoHS compliant, adhering to the latest environmental standards and regulations. The NB100LVEP56MN is fully compatible with existing ECL systems and can be interfaced with LVPECL, CML, or LVDS logic levels with appropriate biasing networks.

ON Semiconductor's commitment to quality is evident in the NB100LVEP56MN, with features like the cold sparing capability, which allows the outputs to remain in the high impedance state while the device is powered down. This ensures that the flip−flop does not load the bus when deselected or powered off. For designers and engineers looking for a reliable and high-performance solution for their digital systems, the NB100LVEP56MN offers an excellent balance of speed, power, and functionality.
