ON Semiconductor NB100LVEP222FAG Dual 2:1 Mux/Demux

The ON Semiconductor NB100LVEP222FAG is a high-performance, dual 2:1 multiplexer/demultiplexer designed to meet the rigorous demands of high-speed data communication systems. This versatile component is a critical building block for applications requiring the efficient routing of differential signals. The NB100LVEP222FAG operates with a supply voltage range of 2.375V to 3.465V, making it compatible with a variety of system voltages and ensuring flexibility in system design.

Featuring a maximum frequency of 3.2 GHz and a propagation delay of just 175 ps, the NB100LVEP222FAG is engineered for rapid signal processing, making it ideal for high-speed data paths in networking, telecommunications, and computing environments. Its differential design helps to minimize signal skew and provides excellent common-mode noise rejection, which is critical for maintaining signal integrity in noisy electrical environments.

Constructed with ON Semiconductor's advanced bipolar technology, the NB100LVEP222FAG offers robust performance with a low bit-to-bit skew of 15 ps, ensuring precise timing alignment of signals. It is also equipped with an additive phase jitter of 0.2 ps typical, which contributes to its high-quality signal transmission capabilities.

The device features two selectable differential inputs and a single differential output per multiplexer. The selection of the desired input is controlled via the SEL input pin, providing users with a simple and effective means of controlling signal routing. The NB100LVEP222FAG also includes an enable (EN) pin that, when deasserted, forces the outputs to a high impedance state, thus minimizing power consumption when the device is not in active use.

Housed in a compact 32-pin LQFP package, the NB100LVEP222FAG is designed for space-constrained applications, offering a high-density solution without compromising performance. Its operating temperature range of -40°C to +85°C ensures that the device can withstand the thermal challenges of a wide range of operating environments.

In summary, the ON Semiconductor NB100LVEP222FAG is a high-speed, dual 2:1 multiplexer/demultiplexer that provides reliable and efficient signal routing for advanced digital systems. Its fast switching speeds, low skew, and differential design make it an excellent choice for designers looking to optimize their high-speed data paths.
