The MC74VHC1G14DFT2G is a high-speed CMOS Schmitt-trigger inverter fabricated with silicon gate CMOS technology. Designed by ON Semiconductor, a leading innovator in energy-efficient electronics, this device is tailored to deliver high-performance solutions in a compact, single-gate package. The MC74VHC1G14DFT2G is designed to accommodate a wide range of supply voltages, from 2V to 5.5V, making it versatile for various applications.

Key Features

• High Speed: Propagation delay time is significantly reduced, ensuring quick response times suitable for high-frequency applications.
• Low Power Consumption: Ideal for battery-operated and power-sensitive devices due to its low power dissipation.
• High Noise Immunity: The Schmitt-trigger action at all inputs makes the circuit tolerant to slower input rise and fall times, providing enhanced stability in the presence of noise.
• Wide Operating Voltage Range: Compatible with 2V to 5.5V, making it suitable for interfacing with both 3.3V and 5V systems.
• CMOS Technology: Offers the advantage of high noise immunity and low static power consumption.

Applications

The MC74VHC1G14DFT2G is an essential component for a variety of electronic circuits. It is commonly used in applications that require signal conditioning, such as wave shaping and noise elimination. Additionally, it is suitable for use in:

• Logic level translation
• Line drivers
• Filtering noisy signals
• Oscillator circuits
• Glitch-free clock distribution networks

Package and Quality

Packaged in a 5-lead SOT-353 (SC-70) surface-mount package, the MC74VHC1G14DFT2G is designed for space-constrained applications. ON Semiconductor ensures that each device meets rigorous quality standards, providing reliable and consistent performance for industrial, commercial, and consumer electronic products.

In summary, the MC74VHC1G14DFT2G from ON Semiconductor is a versatile, high-performance inverter that is a crucial component for designers looking to enhance signal integrity and operational efficiency in their digital logic circuits.
