ON Semiconductor MC74ACT08DR2G Quad 2-Input AND Gate

The MC74ACT08DR2G is a high-performance, quad 2-input AND gate integrated circuit from ON Semiconductor, designed to operate with exceptional speed and reliability. This device is part of ON Semiconductor's ACT series, which is renowned for its advanced CMOS logic, operating with the speed of bipolar TTL but with significantly lower power consumption.

The MC74ACT08DR2G is fabricated with silicon gate CMOS technology, which ensures that this IC has the optimal combination of high speed and low power operation. It is capable of operating at voltage levels ranging from 4.5V to 5.5V, making it compatible with TTL logic levels and suitable for a variety of digital applications.

This integrated circuit features four independent 2-input AND gates, which are useful in performing the logical conjunction function. The device comes in a compact SOIC-14 package, which is surface-mountable and ideal for space-constrained applications. The MC74ACT08DR2G's small form factor, along with its high noise immunity and low power consumption, makes it an excellent choice for use in a wide range of electronic systems, from simple logic control circuits to complex computing devices.

The MC74ACT08DR2G is designed to have a fast propagation delay time, ensuring rapid response times in critical applications. Additionally, the device has a high fan-out capability, allowing it to drive multiple inputs without the need for additional buffering. This feature simplifies design and reduces component count, leading to more efficient and cost-effective circuit designs.

ON Semiconductor has designed the MC74ACT08DR2G with industry standards in mind, ensuring that it meets or exceeds the requirements of the JEDEC standard no. 7A. The device is also fully specified for partial power-down applications using Ioff, which helps to prevent damaging current backflow through the device when it is powered down.

In summary, the MC74ACT08DR2G from ON Semiconductor is a versatile, high-speed logic gate IC that combines low power consumption with high noise immunity, making it an ideal choice for a broad array of digital applications.
