Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer ON Semiconductor
Packaging Reel - TR
Status Active
Logic Type Binary Counter
Direction Up
Number of Elements 1
Number of Bits per Element 14
Count Rate 17MHz
Trigger Type Negative Edge
Supply Voltage - Operating 3 V to 18 V
Temperature Range - Operating -55°C to 125°C
Mounting SMD (SMT)
Case / Package 16-SOIC
Win Source Part Number 006188-MC14060BDR2G
Family Name MC14060
Introduction Date April 04, 2000
ECCN EAR99
Country of Origin China, Czech Republic, Philippines
Halogen Free Compliant
Estimated EOL Date 2026
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian MC14060BDR2G CAD Model

Description

ON Semiconductor MC14060BDR2G Product Overview

The ON Semiconductor MC14060BDR2G is a versatile and high-performance CMOS 14-stage binary ripple counter, designed to meet the needs of various counting applications in modern electronic systems. This integrated circuit is part of the renowned MC14060B series, which is well-known for its robustness, reliability, and efficiency.

Key Features

  • Binary Counter: The device features a 14-stage binary counter, providing a wide range of counting capabilities.
  • High-Voltage Operation: It is capable of operating with a supply voltage ranging from 3V to 18V, making it suitable for various power environments.
  • Low Power Consumption: The counter is designed for low power consumption, thus conserving energy and extending battery life in portable applications.
  • Static Operation: The MC14060BDR2G maintains its state stably, ensuring reliable performance without the need for continuous clocking.
  • Oscillator Configuration: An onboard oscillator configuration is provided, which can be used with an external capacitor and two resistors to form an RC oscillator.
  • Buffered Inputs and Outputs: The inputs and outputs are buffered to enhance the driving capabilities and reduce the effects of system loading.

Applications

The MC14060BDR2G is suitable for a wide array of applications including:

  • Time Delay Generators
  • Frequency Dividers
  • Time-Base Generators
  • Counter/Timer Devices
  • Alarm Systems
  • Sequential Control Devices

Package and Quality

The device is offered in a compact SOIC-16 package, which ensures a minimal footprint on PCBs and is suitable for automated surface-mount assembly processes. ON Semiconductor's commitment to quality ensures that each MC14060BDR2G counter is manufactured to the highest standards, with rigorous testing and quality control measures in place to guarantee performance and durability.

For designers and engineers looking for a reliable and efficient binary ripple counter, the ON Semiconductor MC14060BDR2G presents an excellent choice that combines functionality, versatility, and performance in a single component.
