ON Semiconductor MBRS2040LT3G Schottky Barrier Rectifier

The MBRS2040LT3G is a high-performance Schottky Barrier Rectifier designed and manufactured by ON Semiconductor, a leading provider of semiconductor-based solutions. This rectifier is engineered to offer low forward voltage drop, high surge capability, and a robust thermal performance, making it an ideal choice for a variety of applications where efficiency and reliability are paramount.

Key Features

• High Current Capability: The MBRS2040LT3G is capable of handling a forward current of 20A, which makes it suitable for high current applications.
• Low Forward Voltage Drop: With a low forward voltage drop, this device ensures minimal power loss and improves efficiency in the circuit.
• High Surge Capacity: The device can withstand high surge currents, providing reliability in applications susceptible to surge events.
• Power Surface Mount Package: Packaged in an SMB footprint, the MBRS2040LT3G is designed for compact surface mount installations.
• High-Temperature Operation: With an operating junction temperature range from -55°C to +150°C, it is suitable for high-temperature environments.
• Pb-Free, Halogen-Free, and RoHS Compliant: The device is environmentally friendly and compliant with current RoHS directives, making it a responsible choice for electronic designs.

Applications

The MBRS2040LT3G is versatile and can be used in a wide array of applications, including:

• Power supply management
• DC-DC converters
• Free-wheeling diodes in converters and motor control circuits
• Automotive applications
• Telecommunication and portable devices
• Industrial applications

Its robust design ensures that it is a reliable component for use in high frequency rectification and power switching applications. The MBRS2040LT3G is a testament to ON Semiconductor's commitment to providing high-quality, energy-efficient devices for the electronics industry.

Technical Specifications

Some of the technical specifications of the MBRS2040LT3G include:

• Package: SMB
• Peak Repetitive Reverse Voltage (Vrrm): 40V
• Average Rectified Forward Current (Io): 20A
• Operating Junction Temperature (Tj): -55°C to +150°C
• Storage Temperature Range: -55°C to +150°C

For detailed information and datasheets, visit the ON Semiconductor website or contact their support for technical assistance.
