The H11AA814 series from ON Semiconductor represents a line of high-quality optoisolators designed to provide electrical insulation and signal transfer between two isolated circuits. These components are especially crucial in applications where signal integrity and insulation are paramount for both safety and functionality.

Key Features:

• Optical Isolation: The H11AA814 series offers excellent optical isolation, with a typical optoisolator voltage of 5300 Vrms, ensuring that any electrical disturbances do not pass from one side of the circuit to the other.
• AC Input Response: This series is specifically designed to operate with an AC input, making it ideal for handling signals that alternate in polarity.
• Dual Channel: Each device contains two optically coupled pairs, providing flexibility and redundancy in design.
• Industry Standard Package: The H11AA814 is available in a standard 16-pin DIP package, which is widely accepted in the industry and compatible with most PCB designs.
• High Collector-Emitter Voltage: The device supports a high collector-emitter breakdown voltage of 70 V, accommodating a range of signal levels.
• Current Transfer Ratio (CTR): With a CTR range of 20% to 300%, these optoisolators can work efficiently across various input signal conditions.

Applications:

The H11AA814 series is versatile and can be used in a variety of applications including:

• Power supply regulation and monitoring
• AC phase control circuits
• Telecommunication equipment
• Motor control systems
• Industrial control systems
• Computer peripheral interfaces

Quality and Reliability:

ON Semiconductor is known for its commitment to quality, and the H11AA814 series is no exception. These optoisolators are built to meet stringent standards, ensuring reliable performance in even the most demanding environments. Whether you're designing for industrial, commercial, or residential applications, the H11AA814 series offers the performance and reliability you need.
