ON Semiconductor FDMS86263P PowerTrench® MOSFET

The ON Semiconductor FDMS86263P is a high-performance PowerTrench® MOSFET designed to deliver superior power efficiency and density, making it an ideal choice for a wide range of applications. This advanced MOSFET technology is engineered to meet the rigorous demands of modern electronic designs, providing a combination of low on-resistance and low gate charge to optimize power conversion in power supplies, motor drives, and other power-intensive applications.

With its compact and robust Power 56 package, the FDMS86263P is optimized for space-constrained environments while maintaining exceptional thermal performance. This allows designers to achieve higher power densities without compromising on reliability or efficiency. The MOSFET's package is designed to offer excellent power dissipation characteristics, ensuring stable operation even under high current conditions.

The FDMS86263P boasts an R<sub>DS(on) of only 2.5 mOhm at V<sub>GS = 10 V, which significantly reduces conduction losses. Its fast switching characteristics are attributed to a low total gate charge (Q<sub>G) of 47 nC, which minimizes switching losses and improves overall system efficiency. This combination of low on-resistance and gate charge makes the FDMS86263P a highly efficient solution for power management tasks.

In addition to its electrical performance, the FDMS86263P is designed with a 100% avalanche tested ruggedness, ensuring reliability and a longer lifespan even under stressful conditions. This feature provides designers with the confidence to operate the device in applications where unexpected voltage spikes may occur.

The FDMS86263P also supports a wide operating temperature range, maintaining performance across various environmental conditions. This makes it suitable for industrial and automotive applications where temperature extremes are common.

Overall, the ON Semiconductor FDMS86263P PowerTrench® MOSFET is a versatile and reliable component that offers an excellent balance of power efficiency, thermal performance, and ruggedness. Its advanced features ensure that it can meet the needs of engineers looking to optimize their power designs for efficiency and space without sacrificing performance.
