ON Semiconductor CAT28C64BG90 EEPROM

The CAT28C64BG90 from ON Semiconductor is a high-performance, 64-Kilobit Parallel EEPROM (Electrically Erasable Programmable Read-Only Memory) featuring a data retention of at least 100 years and endurance of 100,000 write cycles. This robust storage device is designed for a wide range of applications that require reliable non-volatile memory storage.

Key Features

• Memory Size: 64Kb (8K x 8)
• Interface Type: Parallel
• Speed: 90 ns access time
• Operating Voltage: 4.5V to 5.5V
• Temperature Range: -40°C to +85°C
• Package: 28-pin, 330 mil PDIP, PLCC, or TSOP
• Automatic Write Timing: Internal control timer
• Software Data Protection: Prevents inadvertent writes
• Hardware Data Protection: Write protect pin
• Low Power Consumption: Active current less than 50 mA, standby current less than 100 µA

The CAT28C64BG90 EEPROM is engineered for high-speed data storage and retrieval with its fast 90 ns access time, making it an excellent choice for performance-intensive applications. The parallel interface ensures easy integration into a wide range of systems, providing a straightforward solution for extending the memory capabilities of embedded systems.

One of the standout features of this EEPROM is its robust data protection capabilities. The software data protection mechanism helps to prevent accidental data corruption, ensuring the integrity of your data. Additionally, the hardware write protect feature allows users to lock the data, making it immune to inadvertent changes.

With its low power consumption, the CAT28C64BG90 is ideal for battery-operated and power-sensitive applications. The device operates over a broad voltage range and is suitable for use in harsh environments, thanks to its wide temperature range.

Whether you're designing industrial control systems, telecommunications equipment, or automotive electronics, the CAT28C64BG90 offers a reliable and flexible solution for your non-volatile memory needs. ON Semiconductor's commitment to quality ensures that this EEPROM will provide dependable storage for applications that cannot compromise on data integrity and longevity.
