ON Semiconductor CAT24C04WI-GT3 EEPROM

The ON Semiconductor CAT24C04WI-GT3 is a high-performance, 4-Kb Serial EEPROM (Electrically Erasable Programmable Read-Only Memory) integrated circuit, designed for a wide range of applications that require a reliable and flexible non-volatile memory solution. This EEPROM device utilizes the standard I²C (Inter-Integrated Circuit) protocol, making it an excellent choice for serial data storage that requires low-power operation and a small footprint.

With its robust design, the CAT24C04WI-GT3 ensures data integrity and retention for mission-critical systems, making it an ideal component for use in a variety of fields such as consumer electronics, automotive, industrial control systems, and medical devices. The device operates over a wide voltage range of 2.5V to 5.5V, allowing for versatile power supply options and compatibility with both 3.3V and 5V logic levels.

Key Features:

• Memory Size: 4-Kb (512 x 8)
• Interface: I²C-compatible (2-wire) serial interface
• Write Cycle Time: Fast write cycle times of 5 ms max
• Operating Voltage Range: 2.5V to 5.5V
• Data Retention: 100 years minimum
• Endurance: 1 million write cycles per byte
• Package: 8-pin SOIC package for easy integration
• Temperature Range: Industrial grade operating temperature range from -40°C to +85°C

The CAT24C04WI-GT3 also features a hardware write protection pin (WP), which can be used to lock the entire memory, thus preventing accidental data alteration during operation. Additionally, the device supports a partial and full array write protect function, offering further control over data security.

ON Semiconductor's commitment to quality is evident in the CAT24C04WI-GT3, as it is fabricated with the company's advanced CMOS technology. This ensures low power consumption and high reliability, which are crucial for battery-operated and power-sensitive systems. Whether you're designing a new system or upgrading an existing one, the CAT24C04WI-GT3 EEPROM from ON Semiconductor is a dependable choice for your data storage needs.
