Products specifications

Categories Discrete Semiconductor Products
Manufacturer ON Semiconductor
Packaging Reel - TR
Status Active
Diode Configuration 1 Pair Series Connection
Diode Type Standard
Voltage - DC Reverse (Vr) (Max) 250V
Current - Average Rectified (Io) (per Diode) 225mA (DC)
Voltage - Forward (Vf) (Max) @ If 1.25V @ 200mA
Speed(Frequency) Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) 50ns
Current - Reverse Leakage @ Vr 100nA @ 200V
Operating Temperature - Junction -55°C to 150°C
Mounting SMD (SMT)
Case / Package SOT-23-3 (TO-236)
Win Source Part Number 095715-BAS21SLT1G
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian BAS21SLT1G CAD Model

Description

The ON Semiconductor BAS21SLT1G is a high-performance, surface-mount switching diode designed to meet the requirements of fast electronic circuits. This small signal diode is encapsulated in a compact SOT-23 package, making it ideal for high-density PCB layouts and portable electronic devices.

Key Features

  • High-Speed Switching: The BAS21SLT1G offers quick switching characteristics, with a reverse recovery time that caters to high-speed applications.
  • High Voltage Rating: With a continuous reverse voltage of 250V, this diode can handle high voltage operations, making it suitable for a variety of electronic circuits.
  • Low Leakage Current: The device exhibits low leakage current, which enhances its efficiency and reliability in sensitive applications.
  • Surface Mount Package: The SOT-23 package allows for efficient use of PCB space and is compatible with automated assembly processes.
  • Lead-Free and RoHS Compliant: ON Semiconductor ensures that the BAS21SLT1G meets environmental regulations, including RoHS compliance, minimizing the environmental impact.

Applications

The BAS21SLT1G is versatile and can be used in a variety of applications that require high-speed switching and high voltage capabilities. These applications include:

  • Switching power supplies
  • DC-DC converters
  • High-speed logic circuits
  • Reverse polarity protection
  • General-purpose high-speed switching applications

Product Specifications

Parameter Value Package SOT-23 Continuous Reverse Voltage (V<sub>R) 250V Forward Continuous Current (I<sub>F) 200 mA Reverse Recovery Time (t<sub>rr) 50 ns Operating Temperature Range -55°C to +150°C

Overall, the ON Semiconductor BAS21SLT1G is an excellent choice for designers looking for a high-speed, high-voltage diode that offers reliability and efficiency in a small footprint. Its compliance with environmental standards also makes it a responsible choice for modern electronic designs.
