ON Semiconductor 2N6341 Thyristor SCR

The 2N6341 is a robust Silicon Controlled Rectifier (SCR) manufactured by ON Semiconductor, known for its high reliability and performance in a variety of applications. This SCR is a four-layer, three-terminal device, featuring a unidirectional flow of current and is designed for medium power switching and phase control applications.

Key Features

• Voltage Rating: The 2N6341 is capable of withstanding peak repetitive off-state voltages (Vdrm/Vrrm) up to 600V, making it suitable for a wide range of applications that require high voltage operation.
• Current Capacity: With an average on-state current (IT(AV)) of 12A, this SCR can handle considerable power, suitable for industrial and commercial electrical equipment.
• Gate Trigger Voltage & Current: It has a low gate trigger voltage (Vgt) and current (Igt), which allows for easy triggering with simple gate drive circuitry.
• Surge Capability: The device has a high surge current capability (ITSM), allowing it to handle high overload conditions without failure.
• Thermal Characteristics: The 2N6341 is equipped with excellent thermal properties, ensuring stable operation over its entire temperature range.
• Package: It comes in a TO-220 package, which is widely used and easy to mount on various types of heat sinks for enhanced thermal management.

Applications

The ON Semiconductor 2N6341 is versatile and can be used in a variety of applications such as:

• Motor control circuits
• Industrial power tools
• Battery chargers
• Lighting dimmers
• Controlled rectifier applications
• Capacitive discharge ignition systems
• Voltage and power regulation circuits

Quality and Reliability

ON Semiconductor is known for its commitment to quality, and the 2N6341 SCR is no exception. It is designed to meet stringent standards, ensuring reliable performance even in harsh environments. The device is also RoHS compliant, reflecting ON Semiconductor's dedication to environmental responsibility.

For designers and engineers looking for a dependable SCR with a balance of good performance and affordability, the 2N6341 from ON Semiconductor is an excellent choice. Its robustness and versatility make it ideal for a wide array of power control applications.
