The 1N5950B is a robust Zener diode designed and manufactured by ON Semiconductor, a leading provider of semiconductor-based solutions. This Zener diode is engineered to provide precise voltage regulation, making it an ideal component for a wide range of electronic circuits requiring voltage clamping or reference voltage generation.

Key Features

• Voltage Range: The 1N5950B series offers a wide range of nominal Zener voltages from 3.3 V to 200 V, providing flexibility for various applications.
• Power Dissipation: With a power dissipation rating of 1.5 watts, this diode can handle significant power levels, making it suitable for high-power applications.
• Package: The diode comes in a DO-41 axial leaded package, which is known for its ease of installation and reliability in through-hole PCB designs.
• Thermal Resistance: The device has a low thermal resistance, ensuring efficient heat dissipation and stable operation over a wide temperature range.
• Tolerance: The Zener voltage tolerance is ±5%, providing precise voltage regulation for critical circuit designs.

Applications

The 1N5950B Zener diode is widely used in various electronic applications, including:

• Voltage regulation circuits
• Surge suppression/protection devices
• Switching power supplies
• Consumer electronics
• Industrial electronics

Quality and Reliability

ON Semiconductor is committed to delivering high-quality products. The 1N5950B Zener diode is no exception, with rigorous testing and quality control measures in place to ensure reliability and performance in the field. The product adheres to industry standards for electronic components, ensuring compatibility and long-term stability for your electronic designs.

Environmental Compliance

The 1N5950B is also compliant with environmental regulations, including RoHS (Restriction of Hazardous Substances), which restricts the use of certain hazardous materials in electrical and electronic equipment. This commitment to environmental stewardship makes the 1N5950B an eco-friendly choice for your circuitry needs.
