Same model may have multiple batches, images only for reference.
XM3C-1522-111 Omron – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

XM3C-1522-111

Part No XM3C-1522-111
Manufacturer Omron
Catalog D-Sub, D-Shaped Connectors - Assemblies
Description CONN D-SUB PLUG 15POS R/A SOLDER
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Connector Style D-Sub
Connector Type Plug, Male Pins
Number of Positions 15
Number of Rows 2
Mounting Type Through Hole, Right Angle
Shell Size, Connector Layout 2 (DA, A)
Contact Type Signal
Flange Feature Mating Side, Female Screwlock (M2.6)
Termination Solder
Shell Material, Finish Steel, Nickel Plated
Contact Finish Gold
Contact Finish Thickness 16.0µin (0.41µm)
Material Flammability Rating UL94 V-0
Current Rating (Amps) 5A
Features Shielded
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1624689-XM3C-1522-111
Ultra Librarian 3D Model Ultra Librarian XM3C-1522-111 CAD Model
