SSG-5L3-3H Real Image
Same model may have multiple batches, images only for reference.

SSG-5L3-3H

Part No SSG-5L3-3H
Manufacturer Omron
Catalog Snap Action, Limit Switches
Description SWITCH SNAP ACT SPST-NO 5A 125V  /  Switch SPST-NO Chassis Mount
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Switches>Limit Switches
Mfr Omron Electronics Inc-EMC Div
Series SSG
Package Bulk
Circuit SPST-NO
Switch Function Off-Mom
Current Rating (Amps) 5A (AC), 4A (DC)
Voltage Rating - AC 125 V
Voltage Rating - DC 30 V
Actuator Type Lever, Simulated Roller
Mounting Type Chassis Mount
Termination Style Solder Lug
Ingress Protection IP40
Operating Force 61gf
Release Force 6.118gf
Differential Travel 0.031" (0.8mm)
Overtravel 0.040" (1.0mm)
Temperature Range - Operating -25°C ~ 125°C
Operating Position 0.420" (10.7mm)
Electrical Life 200,000 Cycles
Mechanical Life 10,000,000 Cycles
Base Product Number SSG-5
Other Names SSG5L33H
Standard Package 100
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.50.7000
Win Source Part Number 1233436-SSG-5L3-3H
Ultra Librarian 3D Model Ultra Librarian SSG-5L3-3H CAD Model

Description

The Omron SSG-5L3-3H is a SPST-NO limit switch that features a solder lug termination style and a simulated roller actuator type.

  • Circuit: SPST-NO
  • Termination Style: Solder Lug
  • Actuator Type: Simulated Roller
  • Voltage Rating: 125VAC and 30VDC
  • Electrical Life: 200,000 cycles
  • Mechanical Life: 10,000,000 cycles
  • Operating Force: 61gf
  • Release Force: 6.118gf
  • Differential Travel: 0.031" (0.8mm)
  • Overtravel: 0.040" (1.0mm)
  • Package: Bulk
  • Ingress Protection Rating: IP40
  • Temperature Range: -25°C to 125°C
  • ECCN: EAR99
  • Current Rating: 5A (AC), 4A (DC)
  • HTSUS Code: 8536.50.7000
