G7L-1A-P-80-CB DC12 Real Image
Same model may have multiple batches, images only for reference.

G7L-1A-P-80-CB DC12

Part No G7L-1A-P-80-CB DC12
Manufacturer Omron
Catalog Power Relays, Over 2 Amps
Description RELAY GEN PURPOSE SPST 20A 12V  /  General Purpose Relay SPST-NO (1 Form A) 12VDC Coil Through Hole
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Relays>Power Relays, Over 2 Amps
Mfr Omron Electronics Inc-EMC Div
Series G7L
Package Bulk
Mounting Type Through Hole
Coil Voltage 12VDC
Contact Form SPST-NO (1 Form A)
Contact Rating (Current) 20 A
Switching Voltage 250VAC - Max
Coil Current 158 mA
Coil Type Non Latching
Termination Style PC Pin
Coil Insulation Class B
Must Operate Voltage 9 VDC
Must Release Voltage 1.8 VDC
Operate Time 30 ms
Release Time 30 ms
Temperature Range - Operating -25°C ~ 60°C
Contact Material Silver Tin Indium (AgSnIn)
Relay Type General Purpose
Coil Resistance 75 Ohms
Base Product Number G7L
MSL Level Not Applicable
ECCN EAR99
HTSUS 8536.41.0050
Other Names G7L-1A-P-80-CB DC12-ND,G7L-1A-P-80-CBDC12,G7L-1A-P-80-CBDC12-ND,G7L1AP80CBDC12,Z11043
Standard Package 20
Win Source Part Number 1060381-G7L-1A-P-80-CB DC12
Ultra Librarian 3D Model Ultra Librarian G7L-1A-P-80-CB DC12 CAD Model

Description

The Omron 1060381-G7L-1A-P-80-CB DC12 is a power relay that has a SPST-NO (1 Form A) contact form and a contact material of silver tin indium (AgSnIn). It has a coil resistance of 75 Ohms and a coil current of 158 mA. The operate and release time of this relay is 30 ms, and it has a contact rating of 20 A at 250VAC. This relay is RoHS compliant and is categorized under Relays > Power Relays, Over 2 Amps. It is currently experiencing a shortage in supply and demand.
