D2SW-P01L1H Omron
Same model may have multiple batches, images only for reference.

D2SW-P01L1H

Part No D2SW-P01L1H
Manufacturer Omron
Catalog Snap Action, Limit Switches
Description SWITCH SNAP ACT SPDT 100MA 125V / Switch SPDT Chassis Mount
Datasheet
D2SW-P01L1H Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Switches - Limit Switches
Mfr Omron
Series D2SW-P
Package Bulk
Product Status Active
Circuit SPDT
Switch Function On-Mom
Current Rating (Amps) 100mA (AC/DC)
Voltage Rating - AC 125 V
Voltage Rating - DC 30 V
Actuator Type Lever, Straight
Mounting Type Chassis Mount
Termination Style Solder Lug
Ingress Protection IP67 - Dust Tight, Waterproof
Operating Force 61gf
Release Force 5.099gf
Operating Position 0.345" (8.8mm)
Differential Travel 0.031" (0.8mm)
Overtravel 0.030" (0.76mm)
Temperature Range - Operating -20°C ~ 70°C
Electrical Life 200,000 Cycles
Mechanical Life 1,000,000 Cycles
Base Product Number D2S
Standard Package 500 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.50.7000
Win Source Part Number 583463-D2SW-P01L1H
Ultra Librarian 3D Model Ultra Librarian D2SW-P01L1H CAD Model

Description

The D2SW-P01L1H is a limit switch from Omron's D2SW-P series.

  • Termination Style: solder lug
  • Ingress Protection: IP67, making it dust tight and waterproof
  • Voltage Rating: 125V AC and 30V DC
  • Current Rating: 100mA
  • Circuit: single-pole double-throw (SPDT)
  • Switch Function: on-mom
  • Actuator Type: lever
  • Operating Force: 61gf
  • Mechanical Life: 1,000,000 cycles
  • Electrical Life: 200,000 cycles
  • Mounting: chassis mount
  • Operating Temperature: -20°C to 70°C
  • Status: active
