Same model may have multiple batches, images only for reference.
A6H-2101-R100 Real Image
Same model may have multiple batches, images only for reference.

A6H-2101-R100

Part No A6H-2101-R100
Manufacturer Omron
Catalog DIP Switches
Description SWITCH SLIDE DIP SPST 25MA 24V / Dip Switch SPST 2 Position Surface Mount Slide (Standard) Actuator 25mA 24VDC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Switches>DIP Switches
Mfr Omron Electronics Inc-EMC Div
Series A6H
Package Tape & Reel
Circuit SPST
Number of Positions 2
Current Rating (Amps) 25mA
Voltage Rating 24VDC
Actuator Type Slide (Standard)
Actuator Level Flush, Recessed
Height Above Board 0.061" (1.55mm)
Mounting SMD (SMT)
Termination Style Gull Wing
Pitch 0.050" (1.27mm), Half
Washable No
Temperature Range - Operating -20°C ~ 70°C
Length 0.148" (3.77mm)
Mechanical Life 1,000 Cycles
Electrical Life 1,000 Cycles
Base Product Number A6H
Other Names A6H-2101-P,Z12735TR,A6H-2101-P,Z12735CT,A6H2101R100,A6H2101P,Z12735DKR
Standard Package 100
MSL Level Not Applicable
ECCN EAR99
HTSUS 8536.50.9065
Win Source Part Number 1233685-A6H-2101-R100
Ultra Librarian 3D Model Ultra Librarian A6H-2101-R100 CAD Model

Description

The Omron A6H-2101-R100 is a DIP switch that is perfect for use in various electronic devices.

  • Manufacturer: Omron
  • Circuit: Single-pole single-throw (SPST)
  • Number of Positions: 2
  • Pitch: 0.050 inches
  • Termination Style: Gull-wing
  • Height Above Board: 0.061 inches
  • Length: 0.148 inches
  • Mechanical Life: 1,000 cycles
  • Electrical Life: 1,000 cycles
  • Operating Temperature: -20°C to 70°C
