PESD1CAN,215

Part No PESD1CAN,215
Manufacturer NXP / Nexperia
Catalog TVS - Diodes
Description ESD Protection Diodes / TVS Diodes CAN bus ESD protection diode
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Nexperia USA Inc.
Packaging Reel - TR
Status Active
Type Zener
Bidirectional Channels 2
STAND-OFF Voltage (Vwm) 24V (Max)
Minimum Breakdown Voltage 25.4V
Max Clamping Voltage 70V
Peak Pulse Current(Ippm) 3A (8/20μs)
Power Dissipation - Pd 200W
Applications CAN
Capacitance @ Frequency 11pF @ 1MHz
Temperature Range - Operating -65°C to 150°C (TA)
Mounting SMD (SMT)
Case / Package SOT-23 (TO-236AB)
Win Source Part Number 061425-PESD1CAN,215
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Automotive, Communications & Networking
Family Name PESD1CAN
Introduction Date January 25, 2005
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian PESD1CAN,215 CAD Model

Description

PESD1CAN,215 from NXP / Nexperia is a TVS diode intended for circuit protection in applications where sensitive electronics may be exposed to transient voltage events. Devices in this category are commonly considered for protecting communication lines, interface ports, automotive networks, and other signal paths that can be affected by electrostatic discharge or surge conditions. For engineers, this part is positioned as a compact protection component that can help improve system robustness without adding major design complexity. It may be relevant in control modules, industrial electronics, consumer devices, and embedded systems where signal integrity and reliability matter. The current lifecycle status for PESD1CAN,215 is information not available, so design teams should confirm ongoing production status directly with the manufacturer or authorized sources before committing it to new programs. RoHS compliance information is also not available in the provided input and should be verified through official datasheets, manufacturer declarations, or distributor compliance documentation.
